DESCRIPTION
LASER CLEANING EQUIPMENT
CL200 is a laser cleaning system designed to remove rust, paint, grease, and other residues from all types of metal and technical surfaces. This equipment enables thorough cleaning without damaging surfaces and without the need for chemicals or consumables.
WHY CL200?
- Portable and compact: easy to transport and use in different environments.
- Easy to use: does not require specialized technicians. Minimal training.
- Precise and localized cleaning: even in small gaps or delicate areas.
- Clear and customizable interface: total control of the process.
- 10m optical cable: ideal reach for remote cleaning.
- No chemicals or consumables: clean and sustainable operation.
- Low maintenance: robust and stable system.
SPECIFICATIONS
TECHNICAL SHEET
| Power input: | 230 V / 50 – 60 Hz |
| Consumption: | 2700W |
| Ambient temperature operation: | 10-40ºC |
| Ambient humidity operation: | ≤80% |
| Average laser power: | 200W |
| Repetition frequency (KHz): | 10-50 |
| Cleaning efficiency (m2/h): | 9 |
| Dimensions [L x W x H]: | 630 x 100 x 109 mm 14.1 x 3.9 x4.2 inches |
| Weight: | 200 kg / 90.71 Ibs |
| Cable length: | 5m |
| Gun weight: | 3 Kg |
| Scanning width: | 10-1000 mm |
APPLICATIONS
• Rust removal on metal structures.
• Cleaning of industrial residues and grease on machinery.
• Surface preparation for welding or painting.
• Non-contact restoration of metal parts.
• Cleaning of rubber or tire molds.
